Anma Voltajı Rated Voltage |
Kod Code |
Kablo Kesiti/ Cross. Sec.Of Cable (mm ² ) |
D (mm) | L (mm) | Kablo Çapı Diameter of Cable (mm ² ) |
---|---|---|---|---|---|
0.6-1 kV | FS1-31610 | 3x16+10 | 34 | 330 | 22 |
FS1-32516 | 3x25+16 | 42 | 330 | 25 | |
FS1-33516 | 3x35+16 | 42 | 330 | 27 | |
FS1-35025 | 3x50+25 | 56 | 330 | 31 | |
FS1-37035 | 3x70+35 | 72 | 330 | 35 | |
FS1-39550 | 3x95+50 | 72 | 330 | 40 | |
FS1-31207 | 3x120+70 | 94 | 500 | 45 | |
FS1-31507 | 3x150+70 | 94 | 500 | 48 | |
FS1-31859 | 3x185+95 | 125 | 500 | 53 | |
FS1-32401 | 3x240+120 | 127 | 500 | 60 | |
FS1-33001 | 3x300+150 | 133 | 500 | 68 | |
FS1-34001 | 3x400+185 | 138 | 500 | 76 | |
FS1-4105 | 4x1,5 | 30 | 330 | 13 | |
FS1-4205 | 4x2,5 | 30 | 330 | 14 | |
FS1-404 | 4x4 | 30 | 330 | 16 | |
FS1-406 | 4x6 | 30 | 330 | 17 | |
FS1-410 | 4x10 | 32 | 330 | 20 | |
FS1-416 | 4x16 | 32 | 330 | 23 | |
FS1-425 | 4x25 | 41 | 500 | 26 | |
FS1-435 | 4x35 | 41 | 500 | 29 | |
FS1-450 | 4x50 | 55 | 500 | 33 | |
FS1-470 | 4x70 | 71 | 500 | 38 | |
FS1-495 | 4x95 | 71 | 500 | 43 | |
FS1-4120 | 4x120 | 93 | 500 | 46 | |
FS1-4150 | 4x150 | 93 | 500 | 47 | |
FS1-4185 | 4x185 | 124 | 500 | 52 | |
FS1-4240 | 4x240 | 126 | 500 | 57 | |
FS1-4300 | 4x300 | 132 | 500 | 73 | |
FS1-4400 | 4x400 | 140 | 500 | 79 |
